VDV30 - High Pressure Diaphragm Valves

High Pressure Diaphragm Valves

High Pressure Diaphragm Valves

Product FeaturesProduct Features

Brass chrome plated body for inert, reactive, flammable and oxidizing gas and mixtures up to grade 6.0
Stainless steel 316L body for corrosive gases
Inlet pressure max. 300 bar
Left or Right lever direction for shutoff
Wide range of inlets / outlets
Metal-to-metal sealing to atmosphere
Tested for use with oxygen

ParameterParameter

Inlet pressure
max. 300 bar (60 bar option)
Inlet / Outlet connection
1/4”NPT(F)
Temperature range
-30℃ to 74℃
Leak rate
1x10-8 mbar I/s He
Orifice
Φ2.7mm

Material QualityMaterial Quality

Body
316L / Chrome Plated Brass
Seat Valve
PCTFE
Diaphragm
Elgiloy®
Filter
SS316L
