VDV1 - Diaphragm Valves
Diaphragm Valves
Diaphragm Valves
Product FeaturesProduct Features
  • Brass chromed plated body and bonnet for inert, reactive, flammable and oxidizing gas and mixtures up to grade 6.0
  • Stainless steel 316L for corrosive gases
  • Wide range of inlets / outlets
  • Suitable for inlet pressure up to 60 bar, hand wheel design
  • Metal-to-metal sealing to atmosphere
  • Tested for use with oxygen
ParameterParameter
  • Inlet pressure
    max. 60 bar
  • Inlet / outlet connection
    1/4”NPT(F)、3/8"NPT(F)
  • Temperature range
    -30℃ to +74℃
  • Leak rate
    1X10-8 mbar I/s He
  • Orifice
    Ф4mm
Material QualityMaterial Quality
  • Body
    316L / Chrome Plated Brass
  • Seat Valve
    PEEK
  • Diaphragm
    Elgiloy®
  • Filter
    SS 316L
