VDV31 - High Pressure Diaphragm Valves
High Pressure Diaphragm Valves
High Pressure Diaphragm Valves
Product FeaturesProduct Features
  • Stainless steel 316L body for corrosive gases
  • Inlet pressure max. 300 bar
  • Left or Right lever direction for shutoff
  • Wide range of inlets / outlets
  • Metal-to-metal sealing to atmosphere
ParameterParameter
  • Inlet pressure
    max. 300 bar (60 bar option)
  • Inlet / Outlet connection
    see ordering info
  • Temperature range
    -30℃ to +74℃
  • Leak rate
    1x10-8 mbar I/s He
  • Orifice
    Φ2.7mm
Material QualityMaterial Quality
  • Body
    316L
  • Seat Valve
    PCTFE
  • Diaphragm
    Elgiloy®
  • Filter
    SS 316L
