VDV2 - Diaphragm Valves

Diaphragm Valves

Diaphragm Valves

Product FeaturesProduct Features

Brass chrome plated body for inert, reactive, flammable and oxidizing gas and mixtures up to grade 6.0
Stainless steel 316L body for corrosive gases
Suitable for inlet pressure up to 60 bar, hand wheel design
Wide range of inlets / outlets
Metal-to-metal sealing to atmosphere
Tested for use with oxygen

ParameterParameter

Inlet pressure
max. 60 bar
Inlet / Outlet connection
1/4”NPT
Temperature range
-30℃ to +74℃
Leak rate
1x10-8 mbar I/s He
Orifice
Φ3.2mm

Material QualityMaterial Quality

Body
316L / Chrome Plated Brass
Seat Valve
PEEK
Diaphragm
Hastelloy® C276
