VSR-120 - Hydrogen Pressure Regulators

Hydrogen Pressure Regulators

Hydrogen Pressure Regulators

Product FeaturesProduct Features

Low pressure, high flow regulator
Stainless steel 316L body， Aluminum body
A variety of hole design, suitable for a variety of inlet and outlet gas structure
Stable output pressure
Simple outlet pressure limitation by handwheel
Tested for use with oxygen

ParameterParameter

Inlet pressure P1
max. 15 bar
Outlet pressure P2
1/2/4/7 bar
Inlets and Outlets
1/8”(standard)，1/4”(option）
Temperature range
-30℃ to +74℃
Leak rate (to atmosphere)
1x10-8mbar I/s He
Leak rate (via seat)
1x10-6mbar I/s He

Material QualityMaterial Quality

Body
316L / Aluminum
Valve seat
Viton®(FKM)
Diaphragm
PTFE+Neoprene
O-ring
Viton®(FKM) / Kalrez®(FFKM) optional
Filter
SS 316L
