VSR-9 - Hydrogen Pressure Regulators

Hydrogen Pressure Regulators

Hydrogen Pressure Regulators

Product FeaturesProduct Features

Piston-sensed design provides a long service life and enhanced safety
High flow and minimal flow droop
Balanced valve design minimizes supply pressure effect
Used in diverse applications for a broad range of temperatures, flows and pressures
Wide variety of preset outlet pressure are available
10 micron, 316 Stainless Steel filter

ParameterParameter

Inlet pressure P1
max. 350 / 700 bar
Outlet pressure P2
8/10/20/30 bar
Leak rate
Bubble-tight
Operating temperature
-40℃ to +85℃
Flow capacity
Cv=0.50

Material QualityMaterial Quality

Body
316L / Aluminium
Valve seat
Vespel®
O-ring
EPDM
Main valve
316L
Sensor
316L
Spring
316L
Filter
10μm 316
