High Pressure Regulators

HP

Current Location

VSR-36 - High Pressure Regulators

High Pressure Regulators

High Pressure Regulators

Product FeaturesProduct Features

Pressure regulator, piston type
Brass body for inert, reactive, flammable and oxidizing gas and mixtures up to grade 6.0
Stainless steel 316L body for corrosive gases
5 Ports flexible configuration
Stable outlet pressure
Simple outlet pressure limitation by handwheel
Inlet filter
Tested for use with oxygen

ParameterParameter

Inlet pressure P1
max. 300 bar
Outlet pressure P2
20/40/60 bar
Inlets and Outlets
1/4" 1/2" 3/4" NPT(F)
Temperature range
-30℃ to +74℃
Leak rate
Bubble-tight
Flow capacity
Cv=2.0

Material QualityMaterial Quality

Body
316L / Chrome plated brass
Valve seat
PCTFE
O-ring
Viton® (FKM)
Filter
SS 316L
