VSR-31 - High Pressure Self-venting Regulators

High Pressure Self-venting Regulators

High Pressure Self-venting Regulators

Product FeaturesProduct Features

Piston sensed for high reliability and long service life
Brass or Stainless Steel construction
For pilot type pressure reducing system
4 ports flexible configuration
Stable outlet pressure
Simple outlet pressure limitation by handwheel
Adjustable and stoppable ultimate maximum outlet pressure

ParameterParameter

Inlet pressure P1
max. 300 bar
Outlet pressure P2
2/4/8/10/20 bar
Inlets and Outlets
1/4” NPT(F)
Temperature range
-30℃ to +74℃
Leak rate
Cv=0.07

Material QualityMaterial Quality

Body
316L / Chrome Plated Brass
Valve seat
PCTFE
O-ring
Viton®(FKM) / Kalrez®(FFKM) optional
Filter
SS 316L
