VSR-8 - High Pressure Self-venting Regulator

High Pressure Self-venting Regulator

High Pressure Self-venting Regulator

Product FeaturesProduct Features

Piston type high pressure regulator
self-venting standard
Brass chrome plated body and bonnet for inert, reactive, flammable and oxidizing oxidizing gas and mixtures up to grade 6.0
Stainless steel 316L body for pharmaceutical, food and beverage application
4 ports flexible configuration
Stable outlet pressure
Simple outlet pressure limitation by handwheel
Inlet filter
Tested for use with oxygen

ParameterParameter

Inlet pressure P1
Brass：max. 400 bar 316L: max. 400/700 bar
Outlet pressure P2
35/50/100/200//300/400 bar
Inlets and Outlets
1/4”NPT (F)
Temperature range
-30℃ to +74℃
Leak rate
Bubble-tight
Flow capacity
Cv=0.06

Material QualityMaterial Quality

Body
316L / Chrome Plated Brass
Main valve seat
Vespel®
Vent valve seat
PCTFE
Piston
SS 316L
O-ring
Viton® (FKM)； Kalrez®(FFKM)
Filter
SS 316L
