VSR-52 - Back Pressure Regulators

Back Pressure Regulators

Back Pressure Regulators

Product FeaturesProduct Features

Economical, compact design
Piston sensed design is safe and reliable
Available in a Stainless Steel or Brass design
Optional gauge ports and panel mounting
Low handknob torque for easy operation
Bubble-tight shutoff at all reseating pressures
Tested for use with oxygen

ParameterParameter

Inlet pressure P1
max. 50 bar
Controlled pressure
see ordering info
Inlets and Outlets
1/4”NPT(F)
Temperature range
-30℃ to +74℃
Leak rate
Bubble-tight
Flow capacity
Cv=0.1

Material QualityMaterial Quality

Body
316L / Chrome Plated Brass
Valve seat
PCTFE / Vespel®
Piston
SS 316L
O-ring
Viton® (FKM) / Kalrez® (FFKM) 可选
Filter
SS 316L
