VSR-10F - Pressure Regulator
Pressure Regulator
Pressure Regulator
Product FeaturesProduct Features
  • Line pressure regulator
  • Stainless steel 316L body
  • 3 or 4 ports configuration
  • Stable outlet pressure
  • Tested for use with oxygen
ParameterParameter
  • Inlet pressure P1
    max. 20 bar
  • Outlet pressure P2
    2/3/4/7/10 bar
  • Inlets and Outlets
    see ordering info
  • Temperature range
    -15℃~+74℃
  • Leak rate
    Bubble-tight
  • Flow capacity
    Cv=10
Material QualityMaterial Quality
  • body
    316L
  • Valve seat
    EPDM
  • Diaphragm
    PTFE+Neoprene
Download
