VSR-4F - Pressure Regulator
Pressure Regulator
Pressure Regulator
Product FeaturesProduct Features
  • Line pressure regulator
  • Stainless steel 316L body
  • 4 ports configuration
  • Stable outlet pressure
ParameterParameter
  • Inlet pressure P1
    max. 35 bar
  • Outlet pressure P2
    2/3/4/8/10/20 bar
  • Inlets and Outlets
    see ordering info
  • Temperature range
    -15℃ to +74℃
  • Leak rate
    Bubble-tight
  • Flow capacity
    Cv=5.1
Material QualityMaterial Quality
  • body
    316L
  • Valve seat
    EPDM (Buna-N optional)
  • Diaphragm
    PTFE+Neoprene
