VSR-3F - Pressure Regulator

Pressure Regulator

Pressure Regulator

Product FeaturesProduct Features

Line pressure regulator
Stainless steel 316L body
4 ports configuration
Stable outlet pressure

ParameterParameter

Inlet pressure P1
max. 40 bar
Outlet pressure P2
2/3/4/10/20/V2/V10 bar
Inlets and Outlets
see ordering info
Temperature range
-30℃ to +74℃
Leak rate (to atmosphere)
1x10-8 mbar l/s He
Leak rate (via seat)
1x10-6 mbar l/s He
Flow capacity
Cv=1.7

Material QualityMaterial Quality

body
316L
Valve seat
PCTFE
Diaphragm
Hastelloy® C276
O-ring
Viton® (FKM) / Kalrez® (FFKM) optional
Filter
SS 316L
