VSR-16M - Pressure Regulator
Pressure Regulator
Pressure Regulator
Product FeaturesProduct Features
  • Lightweight piston pressure reducer
  • The body is 6061 aluminum with anodized surface
  • Compact design, weight only 225g
  • Up to four 1/4 "NPT, or SAE threaded connectors
  • Stainless steel optional
  • Tested for use with oxygen
ParameterParameter
  • Inlet Pressure
    Max. 300 bar
  • Inlets/Outlets
    1/4”NPT(F)
  • Leak Rate
    Bubble-tight
  • Flow Capacity
    Cv=0.06
Material QualityMaterial Quality
  • Body
    Aluminum / 316L
  • Valve Seat
    PCTFE / PEEK (Vespel® 可选）
  • O-ring
    Viton®
