VSR-1EM - Pressure Regulator
Pressure Regulator
Pressure Regulator
Product FeaturesProduct Features
  • Cylinder pressure regulator with lightweight materials
  • Brass chrome plated or aluminium body and aluminium bonnet for inert, reactive, flammable and oxidizing gas and mixtures up to grade 6.0
  • Stainless steel 316L body and aluminium bonner for corrosive gases
  • Accurate and stable pressure control
  • Minimal internal volume allows for rapid purging and carry-over
  • Various porting configurations are available
  • Tested for use with oxygen
ParameterParameter
  • Inlet pressure P1
    max. 250 bar
  • Outlet pressure P2
    2/4/10 bar
  • Inlets and Outlets
    1/8”1/4”NPT(F)
  • Temperature range
    -30℃ to +74℃
  • External Leakage Allowance
    1x10-6 mbar I/s He
  • Internal Leakage Allowance
    Bubble-tight
  • Flow capacity
    Cv=0.06
Material QualityMaterial Quality
  • Body
    316L / Chrome plated brass / Aluminum
  • Valve seat
    PCTFE
  • Diaphragm
    Hastelloy® C276
  • O-ring
    Viton®(FKM) / Kalrez®(FFKM) optional
  • Filter
    SS 316L
