VEFS1 - Flow Switch
Flow Switch
Flow Switch
Product FeaturesProduct Features
  • Flow thru design free of deadlegs or unswept zones
  • Vacuum to 3,500 psig (241 bar)
ParameterParameter
  • Source pressure
    vacuum to 3500 psig
  • Flow trip reference points
    25/50/100 slpm (N2 at 100 psig)
  • Accuracy
    ±10%
  • Installation orientation
    Vertical within 8º and inlet port at the bottom
  • Operating temperature
    -10~175℉ (-23~80℃)
  • Inlet / Outlet
    1/4” tube weld / VFS fitting
  • Leakage（Outboard）
    2x10-10 mbar I/s He
Material QualityMaterial Quality
  • Body
    SS 316L VAR
