VBMV - Metering Bellows Valve

Metering Bellows Valve

Metering Bellows Valve

Product FeaturesProduct Features

Micrometer-style handle for precise and repeatable flow setting.
Micrometer handle measures stem position in 0.001 in. (0.025 mm) increments.

ParameterParameter

Working pressure
Max. 700 psig
Temperature
Max. 315℃ (600℉)
Flow capacity
Cv = 0.019 with metering stem tip, Cv = 0.30 with regulating stem tip

Material QualityMaterial Quality

Body
316 stainless steel
